Stratos GIGA2.0-B 32/1-30/2,2-R1 Wilo
4677444
MFG #: 2234414
€7.731,00
/ 1.00
- Aansluiting inlaatzijde: Flens
- Aansluiting uitlaatzijde: Flens
- Aansluitstandaard inlaatzijde: EN 1092-2
- Aansluitstandaard uitlaatzijde: EN 1092-2
- Aantal fasen: 3
- Afgegeven motorvermogen (P2): 2,2 kW
- Beschermingsgraad (IP): IP55
- Druk bij volumestroom (BEP): 232,12 kPa
- Druktrap flens aansluiting inlaatzijde: PN 16
- Druktrap flens aansluiting uitlaatzijde: PN 16
- Flensvorm: Rond
- Frequentie: 50/60 Hz
- Hoogte perszijde: 267 mm
- Hoogte zuigzijde: 132 mm
- Isolatieklasse volgens IEC: F
- Kwaliteitsklasse materiaal waaier: PP-GF
- Kwaliteitsklasse pomphuis: Gietijzer EN-GJL-250 (GG 25)
- Lengte hart pers/zuig: 80 mm
- Materiaal pomphuis: Gietijzer
- Materiaal waaier / pompwiel: Polypropyleen (PP)
- Max. debiet: 48,25 m³/h
- Max. opvoerhoogte: 32,38 m
- Max. werkdruk: 16 bar
- Mediumtemperatuur (continu): -20 - 140 °C
- Merk: Wilo
- Met communicatie-interface RS-232: Nee
- Met communicatie-interface RS-485: Nee
- Minimum Efficiëntie Index (MEI): 0,7
- Motor energie-efficiëntieklasse: IE5
- Nom. diameter aansluiting inlaatzijde: DN 50
- Nom. diameter aansluiting uitlaatzijde: DN 32
- Nom. spanning: 400 - 400 V
- Nom. stroom: 3,9 A
- Normmotor: Nee
- Omgevingstemperatuur: 0 - 50 °C
- Pomplengte: 554 mm
- Serie: Stratos GIGA2.0-B
- Toerental: 4080 1/min
- Type: 32/1-30/2,2-R1
- Type aandrijving: Elektrisch
- Uitwendige buisdiameter aansluiting inlaatzijde: 50 mm
- Uitwendige buisdiameter aansluiting uitlaatzijde: 32 mm
- Volumestroom (BEP): 25,37 m³/h
